PRODUCTGUIDE EDITION 3 www.housewatch.com.au
Housewatch Product Guide Edition 3 I www.housewatch.com.au 2 If you’re looking for the best in domestic or commercial security, look no further than Housewatch®. Housewatch® was established in 1989 as a distributor of security lighting, sensors, alarm systems and closed circuit TV to the Australian electrical wholesale industry. It has since evolved to become a respected market leader, trusted by professional lighting, electrical & security contractors across Australia. The quality, reliability and efficiency of all Housewatch® products is taken very seriously, which is one of the reasons why the brand has become a leader in the security distribution field. Listening carefully to customer feedback, Housewatch® products are continuously improved to ensure 100% customer satisfaction. Housewatch® is now a brand of M-Elec, and our professional product range is distributed through the Australian electrical wholesale network. INTRODUCTION LEGEND Weather Resistant E27 G9 Sensor Solar Battery Zoom Function PAR38 E27 PAR38 PAR38 LED Tricolour PAR38 LED Tri-Colour PAR38 PAR38 I
SECURITYLIGHTING SECURITY LIGHTING ALARM SYSTEMS & ACCESSORIES SENSORS & DETECTORS PAGES 5–21 PAGES 39–55 PAGES 23–37 01 03 02
4 Housewatch Product Guide Edition 3 I www.housewatch.com.au SECURITYLIGHTING Pages 6-13 Pages 14-16 Pages 17-21 LED Spotlights Twin & Single Sensor Spotlights Lamp Holders & Lamps PRODUCTS IN THIS SECTION 01
Housewatch Product Guide Edition 3 I www.housewatch.com.au 5 SECURITYLIGHTING SECURITY LIGHTING 01 LED Spotlights 10W & 2 x 10W. .................6-8 LED Spotlights 16W Zoom............................ 9 LED Solar Spotlight 16W............................ 10 LED Spotlights 20W & 40W.................... 11-13 Twin Spot Sensors E27............................... 14 Single Spot Sensors E27............................. 15 Single & Twin Spot Halogen Sensors.......... 16 Single & Twin Lamp Packs. ........................ 17 Single & Twin Halogen Lamp Packs............ 18 Halogen Light Globes. ........................... 19-21
6 Housewatch Product Guide Edition 3 I www.housewatch.com.au SECURITYLIGHTING Description Colour Model LED Spotlight 10W with Motion Sensor White 55-151 LED Spotlight 10W with Motion Sensor Black 55-152 LED Spotlight 10W White 55-153 LED Spotlight 10W Black 55-154 LED SPOTLIGHTS 10W TECHNICAL DATA Mounting Wall Wall Sensor Type Passive IR – Detection Range 12m (front) – Detection Angle 140˚ Rotatable 90º Left to Right – Time on Adjustment 5 sec to 5 mins – Lux Setting (Lux) 0 to 2000 – Light Intensity (Lumens) 1000 1000 Colour Temperature 5000K 5000K SMD Seoul/Cree Seoul/Cree Voltage 100 to 240V AC 50Hz 100 to 240V AC 50Hz Operating Temperature -20˚C to +50˚C -20˚C to +50˚C Environmental Protection IP54 IP54 • Manual override (sensor models only) • Adjustable Time, Distance & Lux (sensor models only) • Quick connect base • Stainless steel screws • Aluminium & polycarbonate ABS construction • Double insulated 55-151 55-154 LED SPOTLIGHTS 138mm 112mm 138mm 160mm 112mm 112mm PAR38 PAR38 PAR38 Sensor Non-Sensor
Housewatch Product Guide Edition 3 I www.housewatch.com.au 7 SECURITYLIGHTING • Manual override (sensor models only) • Adjustable Time, Distance & Lux (sensor models only) • Quick connect base • Stainless steel screws • Aluminium & polycarbonate ABS construction • Double insulated LED SPOTLIGHTS Description Colour Model LED Spotlight 2 x 10W with Motion Sensor White 55-155 LED Spotlight 2 x 10W with Motion Sensor Black 55-156 LED Spotlight 2 x 10W White 55-157 LED Spotlight 2 x 10W Black 55-158 LED SPOTLIGHTS 2 x 10W TECHNICAL DATA Mounting Wall Wall Sensor Type Passive IR – Detection Range 12m (front) – Detection Angle 140˚ Rotatable 90º Left to Right – Time on Adjustment 5 sec to 5 mins – Lux Setting (Lux) 0 to 2000 – Light Intensity (Lumens) 2000 2000 Colour Temperature 5000K 5000K SMD Seoul/Cree Seoul/Cree Voltage 100 to 240V AC 50Hz 100 to 240V AC 50Hz Operating Temperature -20˚C to +50˚C -20˚C to +50˚C Environmental Protection IP54 IP54 55-155 55-158 203mm 146.5mm 203mm 146.5mm 160mm 112mm PAR38 PAR38 PAR38 Sensor Non-Sensor
8 Housewatch Product Guide Edition 3 I www.housewatch.com.au SECURITYLIGHTING LED SPOTLIGHTS Description Colour Model LED Spotlight 2 x 10W with Motion Sensor Black 55-159 LED Spotlight 2 x 10W with Motion Sensor White 55-160 LED SPOTLIGHTS 2 x 10W TRICOLOUR TECHNICAL DATA Mounting Wall Sensor Type Passive IR Detection Range 12m (front) Detection Angle 140˚ Rotatable 90º Left to Right Time on Adjustment 5 sec to 5 mins Lux Setting (Lux) 0 to 2000 Light Intensity (Lumens) 2000 Colour Temperature 3000K - 4000K - 5000K SMD Seoul/Cree Voltage 100 to 240V AC 50Hz Operating Temperature -20˚C to +50˚C Environmental Protection IP54 55-160 203mm 146.5mm 203mm 146.5mm 160mm 112mm • Manual override • Adjustable Time, Distance & Lux • Quick connect base • Stainless steel screws • Aluminium & polycarbonate ABS construction • Double insulated PAR38 PAR38 LED Tri-Colour PAR38 Sensor 55-159
Housewatch Product Guide Edition 3 I www.housewatch.com.au 9 SECURITYLIGHTING LED SPOTLIGHTS LED SPOTLIGHTS 2 x 16W ZOOM TECHNICAL DATA 55-173 55-172 YSD-ZS-2500 250mm 110mm YSD-ZS-2500-140 250mm 143mm YSD-ZS-2500-140 250mm 162.8mm 143mm YSD-ZS-2500 250mm 110mm 163mm • Adjustable lens 5 – 100 degrees • Manual override (sensor models only) • Adjustable Time, Distance & Lux (sensor models only) • Quick connect base • Stainless steel screws • Aluminium & polycarbonate ABS construction PAR38 PAR38 PAR38 Description Colour Model LED Spotlight 2 x 16W White 55-171 LED Spotlight 2 x 16W Black 55-172 LED Spotlight 2 x 16W with Motion Sensor White 55-173 LED Spotlight 2 x 16W with Motion Sensor Black 55-174 Mounting Wall Wall Sensor Type Passive IR – Detection Range 12m (front) – Detection Angle 140º Rotatable 90º Left to Right – Time on Adjustment 5 sec to 5 mins – Lux Setting (Lux) 0 to 2000 – Light Intensity (Lumens) 2500 2500 Colour Temperature 5000K 5000K SMD Seoul/Cree Seoul/Cree Voltage 100 to 240V AC 50Hz 100 to 240V AC 50Hz Operating Temperature -20˚C to +50˚C -20˚C to +50˚C Environmental Protection IP54 IP54 Sensor Non-Sensor
10 Housewatch Product Guide Edition 3 I www.housewatch.com.au SECURITYLIGHTING Description Colour Model LED Spotlight 2 x 8W Solar with Sensor Black 55-176 LED SPOTLIGHTS 2 x 8W SOLAR WITH SENSOR TECHNICAL DATA Mounting Wall Sensor Type Passive IR Detection Range 12m (front) Detection Angle 140º Rotatable 90º Left to Right Time on Adjustment 5 sec to 5 mins Lux Setting (Lux) 0 to 2000 Light Intensity (Lumens) 2000 Colour Temperature 5000K SMD Epistar Voltage 4.0V DC Operating Temperature -15 ˚ C to +50 ˚ C Environmental Protection IP54 55-176 204mm 190mm 1 60mm 92.5mm 1 130mm 164mm 204mm 190mm 19.5mm 17mm 60mm 92.5mm 171mm 130mm 164mm 204mm 190mm 19.5mm 17mm 60mm 92.5mm 171mm 130mm • Adjustable Time, Distance & Lux • 6000 mAh battery • Battery charge time: 8 hrs if 100% discharged • 3W solar panel • Stainless steel screws • Aluminium & polycarbonate ABS construction • 5.5m of cable PAR38 PAR38 PAR38 PAR38 Sensor LED SOLAR SPOTLIGHTS
Housewatch Product Guide Edition 3 I www.housewatch.com.au 11 SECURITYLIGHTING Description Colour Model LED Spotlight 20W with Motion Sensor White 55-244 LED Spotlight 20W with Motion Sensor Black 55-245 LED Spotlight 20W White 55-246 LED Spotlight 20W Black 55-247 LED SPOTLIGHTS 20W TECHNICAL DATA Mounting Wall Wall Sensor Type Passive IR – Detection Range 22m Front – Detection Angle 240˚ Rotatable 90º Left to Right – Time on Adjustment 5 sec to 12 mins – Lux Setting (Lux) 0 to 2000 – Light Intensity (Lumens) 2000 2000 Colour Temperature 5000K 5000K SMD Cree/Epistar Cree/Epistar Voltage 100 to 240V AC 50Hz 100 to 240V AC 50Hz Operating Temperature -20˚C to +50˚C -20˚C to +50˚C Environmental Protection IP54 IP54 • Manual override (sensor models only) • Adjustable Time, Distance & Lux (sensor models only) • Quick Connect base • Stainless steel screws • Aluminium & polycarbonate ABS construction 55-244 55-247 192 mm 138 mm 192 mm 192 mm 138 mm 156 mm 192 mm 174 mm 138 mm 130 mm PAR38 PAR38 PAR38 Sensor Non-Sensor LED SPOTLIGHTS
12 Housewatch Product Guide Edition 3 I www.housewatch.com.au SECURITYLIGHTING LED SPOTLIGHTS Description Colour Model LED Spotlight 2 x 20W with Motion Sensor White 55-240 LED Spotlight 2 x 20W with Motion Sensor Black 55-241 LED Spotlight 2 x 20W White 55-242 LED Spotlight 2 x 20W Black 55-243 LED SPOTLIGHTS 2 x 20W TECHNICAL DATA Mounting Wall Wall Sensor Type Passive IR – Detection Range 22m Front – Detection Angle 240˚ Rotatable 90º Left to Right – Time on Adjustment 5 sec to 12 mins – Lux Setting (Lux) 0 to 2000 – Light Intensity (Lumens) 4000 4000 Colour Temperature 5000K 5000K SMD Cree/Epistar Cree/Epistar Voltage 100 to 240V AC 50Hz 100 to 240V AC 50Hz Operating Temperature -20˚C to +50˚C -20˚C to +50˚C Environmental Protection IP54 IP54 55-240 205 mm 192 mm 192 mm 192 mm 138 mm 156 mm 192 mm 205 mm 130 mm 130 mm • Manual override (sensor models only) • Adjustable Time, Distance & Lux (sensor models only) • Quick Connect base • Stainless steel screws • Aluminium & polycarbonate ABS construction PAR38 PAR38 PAR38 Sensor Non-Sensor 55-243
Housewatch Product Guide Edition 3 I www.housewatch.com.au 13 SECURITYLIGHTING LED SPOTLIGHTS Description Colour Model LED Spotlight 40W White 55-233 LED Spotlight 40W Black 55-234 LED Spotlight 40W with Motion Sensor White 55-235 LED Spotlight 40W with Motion Sensor Black 55-236 LED SPOTLIGHTS 40W • Manual override (sensor models only) • Adjustable Time, Distance & Lux (sensor models only) • Quick connect base • Stainless steel screws • Aluminium & polycarbonate ABS construction 55-233 55-236 184mm 224mm 112mm 112mm 183.5mm 224mm 169mm 112mm PAR38 PAR38 PAR38 184mm 112mm TECHNICAL DATA Mounting Wall Wall Sensor Type Passive IR – Detection Range 22m Front – Detection Angle 240˚ Rotatable 90º Left to Right – Time on Adjustment 5 sec to 12 mins – Lux Setting (Lux) 0 to 2000 – Light Intensity (Lumens) 4000 4000 Colour Temperature 5000K 5000K SMD Epistar Epistar Voltage 100 to 240V AC 50Hz 100 to 240V AC 50Hz Operating Temperature -20˚C to +50˚C -20˚C to +50˚C Environmental Protection IP54 IP54 Sensor Non-Sensor
14 Housewatch Product Guide Edition 3 I www.housewatch.com.au SECURITYLIGHTING TWIN SPOTLIGHTS Description Colour Model Twin Spot Sensor White 55-021 Twin Spot Sensor Black 55-023 TWIN SPOT SENSORS E27 • Manual Override • Adjustable time, distance and Lux • Easy Installation; pre-wired • Stainless steel screws • ABS construction 55-023 55-021 220mm 170mm 184mm Mounting Wall/Ceiling Sensor Type Passive IR Detection Range 12m Front Detection Angle 110˚ Rotatable 90º Left to Right Time on Adjustment 6 sec to 12 mins Lux Setting (Lux) 5 to 2000 Light Intensity (Lumens) – Colour Temperature – Lamp Base E27 Voltage 240V AC 50Hz Operating Temperature -20˚C to +60˚C Environmental Protection IP44 TECHNICAL DATA PAR38 PAR38 E27
Housewatch Product Guide Edition 3 I www.housewatch.com.au 15 SECURITYLIGHTING SINGLE SPOTLIGHTS Description Colour Model Single Spot Sensor White 55-221 Single Spot Sensor Black 55-223 SINGLE SPOT SENSORS E27 55-223 55-221 124mm 250mm Mounting Wall/Ceiling Sensor Type Passive IR Detection Range 12m Front Detection Angle 110˚ Rotatable 90º Left to Right Time on Adjustment 6 sec to 12 mins Lux Setting (Lux) 5 to 2000 Light Intensity (Lumens) – Colour Temperature – Lamp Base E27 Voltage 240V AC 50Hz Operating Temperature -20˚C to +60˚C Environmental Protection IP44 TECHNICAL DATA • Manual Override • Adjustable time, distance and Lux • Easy Installation; pre-wired • Stainless steel screws • ABS construction PAR38 PAR38 E27
16 Housewatch Product Guide Edition 3 I www.housewatch.com.au SECURITYLIGHTING Description Colour Model Twin Halogen Sensor, 33W G9 White 55-121 Single Halogen Sensor, 33W G9 White 55-122 Twin Halogen Sensor, 33W G9 Black 55-123 Single Halogen Sensor, 33W G9 Black 55-124 • Manual override • Adjustable time, distance and Lux • Easy installation; pre-wired • Stainless steel screws • G9 tungsten halogen lamp(s) included • Ceramic lamp holder(s) SINGLE & TWIN HALOGEN SENSORS, G9 55-121 55-124 214mm 108mm 231mm 214mm 108mm 231mm SINGLE & TWIN SPOTLIGHT HALOGEN SENSORS Mounting Wall/Ceiling Sensor Type Passive IR Detection Range 12m Front Detection Angle 110˚ Rotatable 90º Left to Right Time on Adjustment 6 sec to 12 mins Lux Setting (Lux) 5 to 2000 Light Intensity (Lumens) 490/980 Colour Temperature 2700K Lamp Base G9 Voltage 240V AC 50Hz Operating Temperature -20˚C to +60˚C Environmental Protection IP44 TECHNICAL DATA PAR38 PAR38 PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 17 SECURITYLIGHTING SINGLE & TWIN LAMP PACKS • Pre-wired for ease of installation • Adjustable lamp holder • Stainless steel screws • PVC construction • Easy installation 55-015 55-013 SINGLE & TWIN PVC LAMP HOLDER PACK, E27 Description Colour Model Twin Lamp Holder Pack Black 55-013 Twin Lamp Holder Pack White 55-014 Single Lamp Holder Pack Black 55-015 Single Lamp Holder Pack White 55-016 Mounting Wall/Ceiling Lux Setting (Lux) – Light Intensity (Lumens) – Colour Temperature – Lamp Base E27 Voltage 240V AC 50Hz Operating Temperature -20˚C to +60˚C Environmental Protection IP44 TECHNICAL DATA 80mm 80mm 220mm 80mm 80mm 220mm PAR38 E27
18 Housewatch Product Guide Edition 3 I www.housewatch.com.au SECURITYLIGHTING SINGLE & TWIN HALOGEN LAMP PACK Description Colour Model Single Halogen Lamp Pack, 33W G9 Black 55-115 Single Halogen Lamp Pack, 33W G9 White 55-116 Twin Halogen Lamp Pack, 33W G9 Black 55-113 • Pre-wired for ease of installation • Ceramic lamp holder(s) • Single base fits PVC conduit box • Stainless steel screws • G9 tungsten halogen lamp(s) included 55-116 55-113 SINGLE & TWIN HALOGEN LAMP PACK, G9 214mm 100mm 231mm 100mm Mounting Wall/Ceiling Lux Setting (Lux) – Light Intensity (Lumens) 490/980 Colour Temperature 2700K Lamp Base G9 Voltage 240V AC 50Hz Operating Temperature -20˚C to +60˚C Environmental Protection IP44 TECHNICAL DATA PAR38 PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 19 SECURITYLIGHTING LIGHT GLOBES Base G9 Colour Temperature 2500K to 2800K Average Life 1500 Hours Equivalent – Rated Voltage 240V Diameter of Tube 12.8 ± 0.1mm Length of Tube 51 ± 1mm TECHNICAL DATA Description Model G9, 75W, 1300 LM, 2800K 55-200 G9, 60W, 950 LM, 2800K 55-201 G9, 48W, 740 LM, 2750K 55-202 G9, 33W, 400 LM, 2700K 55-203 G9, 18W, 170 LM, 2500K 55-204 • Suitable for halogen models with G9 lamp holders HALOGEN LIGHT GLOBES 55-200 50mm 12mm PAR38
20 Housewatch Product Guide Edition 3 I www.housewatch.com.au SECURITYLIGHTING LIGHT GLOBES HALOGEN LIGHT GLOBES Base G9 Colour Temperature 2750K to 2700K Average Life 1500 Hours Equivalent – Rated Voltage 240V Diameter of Tube 12.8 ± 0.1mm Length of Tube 45mm TECHNICAL DATA Description Model G9, Class C, 42W, 630 LM, 2750K 55-252 G9, Class C, 28W, 370 LM, 2700K 55-253 G9, Class C, 18W, 204 LM, 2700K 55-254 • Energy saving G9 lamp • Suitable for halogen models with G9 lamp holders 55-252 50mm 12mm PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 21 SECURITYLIGHTING LIGHT GLOBES 55-100 Base Bi pin (GY6.35) Colour Temperature 2800K to 2700K ± 100K Average Life 1500 Hours Equivalent – Rated Voltage 240V Diameter of Tube Φ14 ± 0.2mm Length of Tube 52 ± 2mm TECHNICAL DATA Description Model Bi pin, 75W, 1200 LM, 2800K 55-100 Bi pin, 50W, 430 LM, 2700K 55-150 • Suitable for halogen models with Bi-Pin (GY6.35) lamp holders BI PIN HALOGEN LAMPS 52mm 15mm PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 22 SENSORS&DETECTORS PRODUCTS IN THIS SECTION Indoor Sensors Outdoor Sensors Pages 24-30 Pages 31-37 02
Product Guide 2018 I www.housewatch.com.au 23 SENSORS &DETECTORS INDOOR SENSORS Mini Flush Prescence Detectors............ 24-25 Surface Mount Prescence Detector............ 26 Flush Mount Prescence Detector. ......... 27-28 Surface & Flush Mount Prescence Detectors. ............................ 29-30 OUTDOOR SENSORS Stand Alone Sensors............................. 31-37 02 Housewatch Product Guide E ition 3
Housewatch Product Guide Edition 3 I www.housewatch.com.au 24 SENSORS&DETECTORS SENSORS INDOOR Description Colour Model Mini Flush Mount Presence Detector White 55-368PAi MINI FLUSH PRESCENCE DETECTOR, 360 DEGREES TECHNICAL DATA • Manual override • Adjustable time, distance & Lux • Integrated power box • Cutout diameter 38mm • 300mm pre-wired cable • Polycarbonate construction • Minimum load 10W 55-368PAi 48mm 35mm 64mm 48mm 35mm 64mm Mounting Wall/Ceiling Sensor Type Passive IR Detection Range 6m Diameter at a 2.5m Mounting Height Detection Angle 360˚ Adjustable with Lens Shield Time on Adjustment From 5 seconds to 30 minutes Lux Setting (Lux) 5 to 2000 Load - 400W (Max) for LED Lamp - 1000W (Max) for Halogen Lamp - 1000VA/600W (Max) for Low Voltage Halogen Lamp - 600VA/400W (Max) Energy Saving lamp - 1000VA/600W (Max) Fluorescent lamp - 2000W (Max) Incandescent lamp Voltage 240V AC 50Hz Operating Temperature -10˚C to +50˚C Environmental Protection IP55/Class II Cutout ø 38mm PAR38 PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 25 SENSORS&DETECTORS SENSORS INDOOR MINI FLUSH PRESENCE DETECTOR, 360 DEGREES Description Colour Model Mini Flush Mount Presence Detector White 55-451 • Cutout diameter: 33mm • Polycarbonate construction • Minimum load 10W 55-451 Actual Size 80mm 85mm ø38mm 163mm 26 N N L L LD1D2 80mm 85mm ø38mm 163mm 28mm 26mm Mounting Flush Sensor Type Passive IR Detection Range 11m Diameter at a 2.5m Mounting Height Detection Angle 360˚ Fixed Time on Adjustment 1 sec to 15 mins Lux Setting (Lux) 0 to 2000 Load - 2000W max. for Incandescent Light - 1000W max. for Halogen Light - 600VA max. for Low Voltage Halogen Light - 900VA/100˚µF for Fluorescent Light (CFL & PL Lamps) - 600VA (Max) 400W for Energy Saving CFL Lamp - 500VA/400W Max. for LED Lamp Voltage 240V AC 50Hz Operating Temperature 0˚C to +45˚C Environmental Protection IP40 Detector, IP20 Power Box TECHNICAL DATA • Adjustable Time, Distance & Lux • Omni-directional dual element sensor Power Box PAR38 PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 26 SENSORS&DETECTORS SENSORS INDOOR SURFACE MOUNT PRESENCE DETECTOR, 360 DEGREES Description Colour Model Surface Mount Presence Detector White 55-313 55-313 Mounting Ceiling Surface Mount Sensor Type Passive IR Detection Range 8m Diameter at a 2.5m Mounting Height Detection Angle 360º Adjustable with Lens Shield Auto Off Time Adjustment 5 sec to 12 mins & Test Lux Setting (Lux) 5 to 2000 Load - 1200W max. for Incandescent Light - 800W max. for Halogen Lamp - 400VA/250W max. for Low Voltage Halogen Lamp - 200W for Fluorescent Lamp - 200W Max. for LED Lamp Voltage 240V AC 50Hz Operating Temperature 10˚C to +50˚C Environment Protection IP40 TECHNICAL DATA • Adjustable Time, Distance & Lux • Low profile design • Built-in walk test function • Unique lens design provides 360º 'No blind spot' detection angle • Large terminal block • Polycarbonate construction • Minimum load 10W ø115mm 36.8mm 40mm PAR38 PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 27 SENSORS&DETECTORS SENSORS INDOOR FLUSH MOUNT PRESENCE DETECTOR, 360 DEGREES Description Colour Model Flush Mount Presence Detector White 55-312 55-312 ø60mm ø75mm 78mm Mounting Ceiling Flush Mount Sensor Type Passive IR Detection Range 8m Diameter at a 2.5m Mounting Height Detection Angle 360º Adjustable with Lens Shield Auto Off Time Adjustment 5 sec to 12 mins Lux Setting (Lux) 0 to 2000 Load - 1200W max. for Incandescent Light - 800W max. for Halogen Lamp - 400VA/250W max. for Low Voltage Halogen Lamp - 200W for Fluorescent Lamp - 200W Max. for LED Lamp Voltage 240V AC 50Hz Operating Temperature 10˚C to +50˚C Environment Protection IP40 TECHNICAL DATA • Adjustable Time, Distance & Lux • Built-in walk test function • Integrated sensor and power box • Cutout diameter: 65mm • Polycarbonate construction • Minimum load 10W PAR38 PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 28 SENSORS&DETECTORS SENSORS INDOOR 55-465 FLUSH MOUNT PRESENCE DETECTOR, 360 DEGREES Description Colour Model Flush Mount Presence Detector White 55-465 ø80mm 110mm ø80mm ø65mm 110mm 51mm 14mm Mounting Flush Sensor Type Passive IR Detection Range 6m Diameter at a 2.4m Mounting Height Detection Angle 360˚ Adjustable with Lens Shield Time on Adjustment 6 sec to 12 mins Lux Setting (Lux) 5 to 900 Load - 10A Max Voltage Free Contact - 20W – 2300W for Incandescent Light - 20W – 1100W for Halogen Light - 20W – 300W for Low Voltage Halogen Light - 20W – 400W for Fluorescent Light - LED Lamp Max 600W Voltage 240V AC 50Hz Operating Temperature -10˚C to +45˚C Environmental Protection IP40 TECHNICAL DATA PAR38 PAR38 • Adjustable time, distance & Lux • Quad element sensor • Built-in walk test function • Cutout diameter: 65mm • Polycarbonate construction • Minimum load 10W N N L L LD1D2 80mm 163mm 28mm 26mm
Housewatch Product Guide Edition 3 I www.housewatch.com.au 29 SENSORS&DETECTORS SENSORS INDOOR SURFACE/FLUSH MOUNT PRESENCE DETECTOR, 360 DEGREES Description Colour Model Surface/Flush Mount Presence Detector White 55-562PA-M 55-562PA-M Mounting Ceiling Surface/Flush Mount Sensor Type Passive IR + Acoustic Detection Range 12m Diameter at a 2.5m Mounting Height Detection Angle 360º Adjustable with Lens Shield Auto Off Time Adjustment 5 sec to 30 mins Lux Setting (Lux) Adjustable from 10 to 2000Lux Load - 2000W max. for Incandescent Light - 1000W max. for Halogen Lamp - 1000VA/600W max. for Low Voltage Halogen Lamp - 1000VA/600W for Fluorescent Lamp - 400W Max. for LED Lamp Voltage 240V AC 50Hz Operating Temperature -20˚C to +50˚C Environment Protection IP20 TECHNICAL DATA • Manual override • Adjustable Time, Distance & Lux • Acoustic sensor 61-74dB • Side & top cable entries • Surface mount junction box included • Cutout diameter: 65mm • Minimum load 10W ø111.4mm ø111.4mm ø52mm 34.4mm PAR38 PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 30 SENSORS&DETECTORS SENSORS INDOOR SURFACE/FLUSH PRESENCE DETECTOR, 360 DEGREES Description Colour Model Surface/Flush Presence Detector White 55-461 55-461 ø111.5mm ø55mm ø111.5mm 70mm 55mm 30mm 59mm 35mm ø111.5mm ø55mm ø111.5mm 70mm 55mm 30mm 59mm 35mm ø111.5mm ø55mm ø111.5mm 70mm 55mm 30mm 59mm 35 m Mounting Surface or Flush Sensor Type Passive IR Detection Range 7m Diameter at a 2.5m Mounting Height Detection Angle 360˚ Adjustable with Lens Shield Time on Adjustment 5 sec to 30 mins Lux Setting (Lux) 0 to 2000 Load - 2000W max. for Incandescent Light - 1000W max. for Halogen Light - 1000VA max. for Low Voltage Halogen Light - 900VA/100µ F for Fluorescent Light - 600VA (400W) Max. for Energy Saving Lamp (CFL PL Lamps) Voltage 240V AC 50Hz Operating Temperature 0˚C to +45˚C Environment Protection IP44 TECHNICAL DATA PAR38 • Manual override • Adjustable Time, Distance & Lux • Built-in walk test function • Dual element sensor • Cutout diameter: 65mm • polycarbonate construction • Minimum load 10W PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 31 SENSORS&DETECTORS SENSORS OUTDOOR Description Colour Model Stand Alone Sensor 180 Degrees White 55-188 STAND ALONE SENSOR 180 DEGREES TECHNICAL DATA • Adjustable time, distance & Lux • Large terminal block • Energy efficient, less than 0.5W in standby mode • Stainless steel screws • Suitable for HVAC applications • Polycarbonate construction • Minimum load 10W 55-188 119.5mm 73.5mm 65mm 73.5mm PAR38 PAR38 Mounting Wall/Ceiling Sensor Type Passive IR Detection Range 12m at a 2m Mounting Height Detection Angle 180˚ Rotatable 90º Left to Right Time on Adjustment From 5 seconds to 30 minutes Lux Setting (Lux) 10 to 2000 Load - 150W (Max) for LED Lamp - 500W (Max) for Halogen Lamp - 300VA (Max for Low Voltage Halogen Lamp - 250VA/ 150W (Max) Energy Saving lamp - 300VA/ 100W (Max) Fluorescent lamp - 250VA/ 1000W (Max) Incandescent lamp Voltage 240V AC 50Hz Operating Temperature -20˚C to +50˚C Environmental Protection IP65
Housewatch Product Guide Edition 3 I www.housewatch.com.au 32 SENSORS&DETECTORS SENSORS OUTDOOR Description Colour Model Stand Alone Sensor, 120 Degrees White 55-320 STAND ALONE SENSOR 12VAC/DC, 120 DEGREES • Adjustable time, distance & Lux • AC/DC input • Voltage free contact • Stainless steel screws • ABS construction • Suitable for garden lighting, solar lighting, boats and caravans • Minimum load 10W 55-320 117mm 58mm 55mm 82mm ACCESSORIES Description Model 90dB Buzzer 70-415 Replacement Sensor 55-320 Replacement Power Supply 01-121 70-415 01-121 Mounting Wall/Ceiling Sensor Type Passive IR Detection Range 10m at a 2.5m Mounting Height Detection Angle 120˚ Rotatable 130º Left to Right 60º Down Time on Adjustment 6 sec to 12 mins Lux Setting (Lux) 0 to 2000 Load - Switching Contact: Voltage Free Contact -10A Max for 12-240VAC -10A Max for 12 – 30VDC Voltage 12V ±10∞ DC or AC 50-60Hz Operating Temperature -20˚C to +45˚C Environmental Protection IP44 TECHNICAL DATA PAR38 PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 33 SENSORS&DETECTORS SENSORS OUTDOOR 12-24V AC OR 11-32V DC STAND ALONE SENSOR, 180 DEGREES Description Colour Model Stand Alone Sensor, 180 Degrees White 55-186UC 55-186UC Mounting Ceiling/Wall Mount Sensor Type Passive IR Detection Range 12m at a 2m Mounting Height Detection Angle 180º Rotatable 90º Left to Right Auto Off Time Adjustment 6 sec to 12 mins Lux Setting (Lux) 10 to 2000Lux Load Max. Switching Contact Voltage Free Contact Voltage 12-24V AC 50/60Hz, or 11-32 VDC Operating Temperature -20˚C to +50˚C Environment Protection IP44 TECHNICAL DATA • Adjustable Time, Distance & Lux • Large terminal block • Voltage free contacts • Approx. 0.2mA standby power • ABS construction • Minimum load 10W 60mm 108mm 60mm 114mm 64mm 55mm 108mm PAR38 PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 34 SENSORS&DETECTORS SENSORS OUTDOOR Description Colour Model Stand Alone Sensor, 110 Degrees White 55-105 • Manual override • Adjustable time, distance & Lux • Energy efficient less than 0.25W in standby mode • Stainless steel screws • ABS construction • Minimum load 10W 55-105 STAND ALONE SENSOR, 110 DEGREES Mounting Wall/Ceiling Sensor Type Passive IR Detection Range 14m at a 2.5m Mounting Height Detection Angle 110˚ Rotatable 30º Left to Right Time on Adjustment 6 sec to 12 mins Lux Setting (Lux) 0 to 2000 Load - 1000W (Max) for Incandescent Lights - 500W (Max for Halogen Lights - 400VA (Max) for Fluorescent Lights - 400VA (Max) for Energy Saving Lights (including CFL & PL) - 200W (Max) for LED Lights Voltage 240V AC 50Hz Operating Temperature -20˚C to +45˚C Environmental Protection IP55 TECHNICAL DATA 86mm 199mm 102.5mm 86mm 199mm 102.5mm PAR38 PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 35 SENSORS&DETECTORS SENSORS OUTDOOR Description Colour Model Stand Alone Sensor, 110 Degree Black 55-101 Stand Alone Sensor, 110 Degree White 55-110 Stand Alone Sensor, 110 Degree Silver 55-102 Stand Alone Sensor, 110 Degree Beige 55-103 STAND ALONE SENSOR, 110 DEGREES • Manual override • Adjustable time, distance & Lux • Power consumption less than 1W • Stainless steel screws • ABS construction • Minimum load 10W 55-102 193mm TOP ø80mm 80mm Mounting Wall/Ceiling Sensor Type Passive IR Detection Range 12m at a 2.5m Mounting Height Detection Angle 110˚ Rotatable 60º Left to Right Time on Adjustment 6 sec to 12 mins Lux Setting (Lux) 0 to 2000 Load - 1000W (Max) for Incandescent Lights - 500W (Max for Halogen Lights - 250W (Max) for Fluorescent Lights - 150W (Max) for Energy Saving Lights (including CFL & PL) - 200W (Max) for LED Lights Voltage 240V AC 50Hz Operating Temperature -20˚C to +40˚C Environmental Protection IP44 TECHNICAL DATA PAR38 PAR38
Housewatch Product Guide Edition 3 I www.housewatch.com.au 36 SENSORS&DETECTORS SENSORS OUTDOOR STAND ALONE SENSOR, 200 DEGREES TECHNICAL DATA Description Colour Model Stand Alone Sensor, 200 Degrees White 55-036 55-036 • Manual override • Adjustable time, distance & Lux • Energy efficient less than 0.25W in standby mode 201mm ø80mm 80mm Mounting Wall/Ceiling Sensor Type Passive IR Detection Range 12m to 14m at a 2m Mounting Height Detection Angle 200˚ Rotatable 60º Left to Right Time on Adjustment 6 sec to 12 mins Lux Setting (Lux) 0 to 2000 Load - 1000W (Max) for Incandescent Lamp - 400VA (Max) for Low voltage Halogen Lamp - 500W (Max for Halogen Lights - 250W (Max) Uncompensated for Fluorescent lamp Voltage 240V AC 50Hz Operating Temperature -20˚C to +40˚C Environmental Protection IP44 PAR38 PAR38 • Stainless steel screws • ABS construction • Minimum load 10W
Housewatch Product Guide Edition 3 I www.housewatch.com.au 37 SENSORS&DETECTORS SENSORS OUTDOOR Description Colour Model Stand Alone Sensor, 220 Degrees White 55-106 • Manual override • Adjustable time, distance & Lux • Energy efficient less than 0.25W in standby mode 55-106 STAND ALONE SENSOR, 220 DEGREES Mounting Wall/Ceiling Sensor Type Passive IR Detection Range 12m to 14m at a 2.5m Mounting Height Detection Angle 220˚ Rotatable 60º Left to Right Time on Adjustment 6 sec to 12 mins Lux Setting (Lux) 0 to 2000 Load - 1000W (Max) for Incandescent Lamp - 400VA (Max) for Low voltage Halogen Lamp - 500W (Max for Halogen Lights - 400VA (Max) Uncompensated for Fluorescent lamp Voltage 240V AC 50Hz Operating Temperature -20˚C to +45˚C Environmental Protection IP55 TECHNICAL DATA 86mm 101mm 199mm 101mm 199mm PAR38 PAR38 • Stainless steel screws • ABS construction • Minimum load 10W
38 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au PRODUCTS IN THIS SECTION Door Beams Alarms Kits Pages 40–42 Pages 47–50 Pages 43–46 Pages 51–55 Transmitters & Receivers Accessories 03
39 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au 02 ALARM SYSTEMS 3 Door Beams........................................... 40-42 4 Channel RF Transmitter & Receiver........ 43 RF Transmitter Battery.............................. 44 RF Transmitter with Relay. ........................ 45 Transmitter & Receiver.............................. 46 8 Zone Alarm Kit (Standard)....................... 47 8 Zone Alarm Kit (Deluxe). ......................... 48 8 Zone Alarm Kit (Apartment).................... 49 8 Zone Alarm Kit (House). .......................... 50 Dummy Alarm Kit....................................... 51 Alarm Kit Accessories........................... 52-53 Passive Infrared Detectors.................... 54-55
40 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au DOOR BEAM TECHNICAL DATA Description Colour Model Entry Warning System includes Beam Sensor/Reflector, 9V DC Adaptor, Alarm Speaker, 10m Cable, NIR100SA Black 45-100 Power Supply 9V DC Total Current Consumption Maximum≤100mA Standby Current 25mA Detection Range 0.5 to 6m Light Source 9V DC Speaker Output Chime/Off/Alarm (Select by Switch) Speaker Time 1 Second for Chime, 30 Seconds for Alarm (Adjustable 3 – 30) Volume 85db +/- 10% Volume Adjustable Yes • Suitable for shops, reception areas, medical and dental surgeries • Modulated beam of infrared light across a doorway onto a retro-reflector mounted opposite • Alarm will trigger and give an audible warning when people walk through the beam ACCESSORIES Description Model 10m Extension Cable 45-101 20m Extension Cable 45-102 Additional Speaker for Expanding (Requires Extension Cable) 45-103 Counter (Requires Extension Cable) 45-104 Hood for Reflector 45-106 Replacement Power Supply 01-123 45-100 45-104 45-103 DOOR BEAMS PAR38
41 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au DOOR BEAMS DOOR BEAM PARADOOR TECHNICAL DATA Description Colour Model Paradoor Detector, Curtain Beam, Timer White 45-250 Paradoor Detector Kit with 12V DC Power Supply, Buzzer White 45-300 Sensor Dual Element, Low Noise, High Response Processing Threshold, APSO, Automatic Temperature Compensation (Metal Shielding) Detection Speed 25mA Power Input 9 to 16V DC or 20-27V DC, 18mA Maximum Lens Lodiff Segment Real Full Curtain Fresnel Lens Coverage Front View – 40°, 1.5m at 5ft, 4.5m at 15ft Side View 2.1m for Card Access, 6.6m for Security Zones 1 (Full Curtain), 2 Positions Alarm/Signal Green LED – 0.5 sec to 25 sec adjustable Alarm Signal Output 0.15/28V, 2A/28VDC Transistor Open Collector, Selectable to N.C. or N.O. Operation Anti Tamper Switch 0.15A, 28V DC, Opens When Cover Removed Operating Temp -10˚C to +50˚C Humidity 95% Maximum • Unique dual element rectangular sensor • Narrow full curtain beam • Can detect movements caused by a hand sized object up to 2.1m and movements of a human body up to 6.6m 45-250 45-300 93mm 115mm PAR38
42 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au DOOR BEAM OUTDOOR TECHNICAL DATA Description Colour Model Photoelectric Beam & Reflector, IP66, 12m, IR1200L Black 45-150 Photoelectric Beam Sensor, IP66, 30m, IR3000L Black 45-200 Detection Type Retro Reflection (45-150) or Through Beam (45-200) Sensing Range 12m (45-150) or 30m (45-200) Output Method Normally Closed Relay Input Voltage 45-150 Both AC/DC 12-240V Free Power 45-200 DC 12-240V +/- 10% or AC 24-240V +/- 10% Response Time 15Ms Emitting Element IR LED Power LED Indicator Green When Powered; LED Turn On When Power Off; LED Turn Off Current Consumption Beam Aligned: 52mA, Broken 32mA Environmental Protection IP66 Operating Temperature -20˚C to -55˚C • Universal AC/DC input voltage • Suitable for warehouse, drive through bottle shop, industrial automation, entry passing detection, gate or garage door 45-150 45-200 01-121 70-415 26-001 ACCESSORIES Description Model 12V DC 1000mA Power Supply for 45-150 and 45-200 01-121 12V DC Buzzer with Cable, 90dB, 12VDC, 22mm Diameter, 12mm High 70-415 Universal Timer Board (For Setting Amount of Time Buzzer Sounds) 26-001 Hood for 45-150 Reflector 45-106 DOOR BEAMS PAR38 PAR38
43 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au FOUR CHANNEL RF TRANSMITTER & RECEIVER Description Colour Model Four Channel RF Transmitter with Key Chain, 12V DC Black 75-063 Four Channel Receiver, 433.92MHz Black 75-064 75-063 Features • Operates up to 150 metres • Over 68 billion possible codes • Includes 12V DC alkaline battery • Dimensions: 60mm x 35mm x 15mm 75-064 Features • One Channel. 433.92MHz • Small size (80 x 65 x 19mm) • Control garage doors, etc. • LED shows RF reception program status • Mode switches for easy transmitter learning 75-063 75-063 75-064 TRANSMITTERS & RECEIVERS 75-064 TECHNICAL DATA Operating Distance 150m Operating Voltage 11 to 24V AC/DC Current Draw 8mA at 12V DC Standby, 45mA at 12V DC LED Flashing Memory Capacity 15 Transmitter Button Codes per Channel Receiver Output Modes Timed Momentary (1, 2, 3, 4, 5, 10, 30, 60 sec) Toggle (ON/OFF), Latched, Continuous Receiver Outputs Form C Dry Relay Contact (N.O/N.C/Com); max 10 Amp and 24VDC Operating Frequency 433.92MHz RF Codes 18 Quintillion Code bump Dimensions 135 x 111 x 28mm Operating Temperature 20˚ to 72˚C 55mm 33mm 106mm 130mm
44 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au TRANSMITTERS & RECEIVERS 75-068 ONE CHANNEL RF TRANSMITTER BATTERY Description Colour Model Single Channel Wired RF Transmitter, 12V DC Battery Black 75-068 • One Channel. 433.92MHz • Control garage doors, etc. • LED shows RF reception program status • LED transmission indicator • Includes 12V DC alkaline battery TECHNICAL DATA Operating Distance 154 Metres Operating Frequency One Channel 433.92MHz Wiring 2 wires (6") for N.O. switch input 2 wires (6") for 12V DC power input Dimensions 57 x 38 x 16mm 38mm 57mm PAR38
45 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au TRANSMITTERS & RECEIVERS ONE CHANNEL RF TRANSMITTER WITH RELAY TECHNICAL DATA Description Colour Model Single Channel Receiver, Relay Output, 433.92MHz Black 75-067 Operating Distance 150m Operating Voltage 11 to 24V AC/DC Current Draw 5mA at 12V DC Standby, 50mA LED Flashing Memory Capacity 15 Transmitter Button Codes per Channel Receiver Output Modes - Timed Momentary (1, 2, 3, 4, 5, 10, 30, 60 sec) - Toggle (ON/OFF) - Latched Continuous Receiver Outputs - 3A Form C Relay (NO/NC/C) Operating Frequency 433.92MHz RF Codes 18 Quintillion Code bump Dimensions 65 x 80 x 19mm Operating Temperature 20˚ to 72˚C 75-067 • One Channel. 433.92MHz • Control garage doors, etc. • LED shows RF reception program status • Mode switches for easy transmitter learning 45mm 60mm
46 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au TRANSMITTER & RECEIVER TECHNICAL DATA Description Colour Model Mini Handheld Transmitter, 12V DC, IP40, TF-69 Dark Grey 55-069 Receiver, Down Light Style, 6A, IP20, RF-150D White 55-070 TRANSMITTER Transmission Range 50m in Open Air IP Rating IP40 Rated Voltage 12V DC (A23 Battery) Transmission Frequency 433.92MH Channel Four to 64 Combinations Operation Temperature 0˚C to +45˚C RECEIVER Transmission Range 50m in Open Air IP Rating IP20 Rated Voltage 240V 50Hz Switching Load - 6A (Max) Voltage Free Contact - Energy Saving Lamp (CFL): 250VA (150W) Max - (Includes CFL & PL Lamp), LED Lamp: Max: 250VA/200W Transmission Frequency 433.92MHz Modulation ASK (Amplitude Shifting Keyring) Cut Out 63mm • Suitable for outdoor or indoor lighting, tennis courts, sheds, garden lighting, pool lights, pool pumps, venetian blind, ventilator • Wireless home automation • Able to control 64 different lighting applications 55-069 55-070 TRANSMITTERS & RECEIVERS 45mm 70mm 80mm 4 80mm 80mm 45mm 80mm 80mm PAR38
47 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au ALARM KITS 8 ZONE ALARM KIT WITH LED KEYPAD & DIALLER (STANDARD KIT) 20-122 50-040 20-122 70-511 70-316 Description Model 8 Zone Standard Alarm Kit with Dialler 20-122 • 8 hard wired zones • 4 programmable phone numbers • Dialler communicates with central station, pager and mobile phone • 127 number of events recorded in memory • 2 separately armable areas and 2 part night modes • Chime mode to alert you of movement on the premises • Simple one touch keypad keys • Built in real time clock Description Model 1 x 8 Zone Control Panel, dialler & LED keypad 20-120 2 x 12V DC PIR detectors 50-040 1 x Combined siren/strobe 70-511 1 x Internal siren 70-316 1 x 12V DC 7Ah battery 01-060 1 x 100m 4 core cable 80-015 1 x Reed switch 25-015 1 x 16V Plug pack 05-127 2 x Alarm stickers 85-208 KIT INCLUDES PAR38
48 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au ALARM KITS 8 ZONE ALARM KIT WITH LED KEYPAD & DIALLER (DELUXE KIT) 20-124 Description Model 8 Zone Deluxe Alarm Kit with Dialler 20-124 • 8 hard wired zones • 4 programmable phone numbers • Dialler communicates with central station, pager and mobile phone • 127 number of events recorded in memory • 2 separately armable areas and 2 part night modes • Chime mode to alert you of movement on the premises • Simple one touch keypad keys • Built in real time clock Description Model 1 x 8 Zone control panel, dialler & LED keypad 20-120 3 x 12V DC PIR detectors 50-040 1 x Combined siren/strobe 70-511 1 x Internal siren 70-316 1 x 12V DC 7Ah battery 01-060 2 x 4 Channel Transmitter (Key fob Style) 75-063 1 x Single Channel Receiver 75-067 2 x Alarm Stickers 85-208 1 x 16V Plug Pack 05-127 KIT INCLUDES 50-040 20-122 70-511 01-060 PAR38
49 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au ALARM KITS • 8 hard wired zones • 4 programmable phone numbers • Dialler communicates with central station, pager and mobile phone • 127 number of events recorded in memory • 2 separately arm able areas and 2 part night modes • Chime mode to alert you of movement on the premises • Simple one touch keypad keys • Built in real time clock 20-830 8 ZONE ALARM KIT WITH LED KEYPAD & DIALLER (APARTMENT KIT) Description Model 8 Zone Deluxe Alarm Kit with Dialler 20-830 Description Model 1 x 8 Zone Control Panel, dialler & LED keypad 20-120 3 x 12V DC PIR detectors 50-040 1 x Combined siren/strobe 70-511 1 x Internal siren 70-316 1 x 12V DC 7Ah battery 01-060 1 x 100m 4 core cable 80-015 2 x Alarm Stickers 85-208 1 x 16V Plug pack 05-127 1 x Totesmall packaging container KIT INCLUDES 50-040 20-122 70-511 80-015 PAR38
50 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au ALARM KITS 20-840 • 8 hard wired zones • 4 programmable phone numbers • Dialler communicates with central station, pager and mobile phone • 127 number of events recorded in memory • 2 separately armable areas and 2 part night modes • Chime mode to alert you of movement on the premises • Simple one touch keypad keys • Built in real time clock 8 ZONE ALARM KIT WITH LED KEYPAD & DIALLER (HOUSE KIT) Description Model 8 Zone Deluxe Alarm Kit with Dialler 20-840 Description Model 1 x 8 Zone Control Panel, dialler & LED keypad 20-120 4 x 12V DC PIR detectors 50-040 1 x Outdoor siren 70-318 1 x Blue strobe 70-512 1 x PVC siren cover 70-600 1 x Tamper switch 65-030 1 x Internal siren 70-316 1 x 12V DC 7Ah battery 01-060 1 x 4 Channel transmitter (key fob style) 75-063 1 x Single channel receiver 75-067 1 x 100m 4 core cable 80-015 2 x Alarm stickers 85-208 1 x 16V Plug pack 05-127 KIT INCLUDES 50-040 20-122 70-318 70-316 PAR38
51 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au ACCESSORIES DUMMY ALARM KIT Description Model Dummy Alarm Kit 70-700 70-700 Kit Includes • 1 x 70-600 PVC outdoor siren cover • 1 x 70-512 blue strobe • 2 x 85-208 alarm stickers ACCESSORIES Description Model PVC Outdoor Siren Cover 70-600 Blue Strobe, 12V DC, 180mA, 75 x 45 (h)mm 70-512 Alarm Stickers 85-208 70-512 70-600 85-208
52 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au ACCESSORIES ALARM KIT ACCESSORIES Description Model 8 Zone Panel with LED Keypad 20-120 8 Zone Panel with LCD Keypad 20-123 16 Zone Panel with LED Keypad 20-144 16 Zone Panel with LCD Keypad 20-141 LED Keypad Only 8/16 Zone 20-143 LCD Keypad Only 8/16 Zone 20-125 12V DC 7AH Battery 01-060 16V AC 1.5 Amp Plug Pack with Earth Lead 05-127 4 Core 7/020 100m Roll Cable 80-015 6 Core 7/020 100m Roll Cable 80-030 Indoor Siren, 12V DC, 110 db, 150 – 200mA, Ivory, 55 x 40 (h)mm 70-316 20-120 20-125 01-060 80-015 70-316
53 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au ACCESSORIES ALARM KIT ACCESSORIES 70-318 25-005 25-015 70-512 70-511 85-208 Description Model Outdoor Siren, 12V DC, 110 db, 10/15W, White, 88 x 105 (h)mm 70-318 Combined Siren & Strobe, 12V DC, 130mA, 110 +/- 3db, Piezo, Wall Mt, IP60, 73 x 122, 43mm 70-511 Blue Strobe, 12V DC, 180mA, 75 x 45 (h)mm 70-512 Surface Mount Reed Switch, Changeover N.O and N.C 25-015 End on Reed Switch 9mm 25-005 Roller Door Reed Large 25-002 Alarm Sticker 85-208 Emergency Button 65-026 Tamper Switch 65-030 Four Channel RF Transmitter with Key Chain, 12V DC 75-063 Single Channel Receiver, Relay Output, 433.92MHz, SK-910RA-4 75-064
54 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au ACCESSORIES 12V DC PASSIVE INFRARED DETECTOR TECHNICAL DATA Description Colour Model 12V PIR Detector, 12m, 104˚, Normally Closed, CQ86 White 50-040 Voltage Range 9-16V AC Volumetric 12m Range, 24 Facets, 104˚Coverage Angle Detection Method Passive IR Detector Type Dual Element, Low Noise Pyro – Electric Sensor Quiescent Current 17mA and 12V (Typical) Alarm Output Normally Closed Pair with 18 Ω Series Resistor Rated at 24V DC 50mA Tamper Output Normally Closed Pair, Rated at 24VDC 50mA Maximum Ripple 2V pp and 12V DC Walk Test LED Link Selectable Alarm Period 2 to 3 Seconds (Typical) Maximum Humidity 95% Non Condensing Operating Temperature -10˚C to 55˚C 50-040 • Suitable for alarm control panels • Temperature compensation • Selectable pulse count • Superior RF immunity • Walk test LED • Tamper protection • Wall or ceiling mount 75mm 62mm 75mm 62mm 39.5mm PAR38
55 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au ACCESSORIES 50-360 PASSIVE INFRARED DETECTOR TECHNICAL DATA Description Colour Model 360˚Ceiling Mount PIR Detector White 50-360 Rated Voltage 12V DC Viewing Angle 360˚ Range 7m x 6m at 2.4m 11m x 6m at 3.7m • Two operational modes (addressable for the Digiplex and Digiplex EVO series or conventional relay operation) • Dual opposed element sensor • Digital detection ø108mm 35mm ø108mm 35mm PAR38
56 ALARMSYSTEMS Housewatch Product Guide Edition 3 I www.housewatch.com.au 01-060.......................................47, 49, 52 05-127.......................................47, 49, 52 20-120.......................................47, 49, 52 20-122.................................................. 47 20-123.................................................. 52 20-124.................................................. 48 20-125.................................................. 52 20-141.................................................. 52 20-143.................................................. 52 20-144.................................................. 52 20-830.................................................. 49 20-840.................................................. 50 25-002.................................................. 53 25-005.................................................. 53 25-015............................................ 47, 53 45-100.................................................. 40 45-150.................................................. 42 45-200.................................................. 42 45-250.................................................. 41 45-300.................................................. 41 50-040.......................................47, 49, 54 50-360.................................................. 55 55-013.................................................. 17 55-014.................................................. 17 55-015.................................................. 17 55-016.................................................. 17 55-021.................................................. 14 55-023.................................................. 14 55-036.................................................. 36 55-069.................................................. 46 55-070.................................................. 46 55-100.................................................. 21 55-101.................................................. 35 55-102.................................................. 35 55-103.................................................. 35 55-105.................................................. 34 55-106.................................................. 37 55-110.................................................. 35 55-113.................................................. 18 55-115.................................................. 18 55-116.................................................. 18 55-121.................................................. 16 55-122.................................................. 16 55-123.................................................. 16 55-124.................................................. 16 55-150.................................................. 21 55-151.................................................... 6 55-152.................................................... 6 55-153.................................................... 6 55-154.................................................... 6 55-155.................................................... 7 55-156.................................................... 7 55-157.................................................... 7 55-158.................................................... 7 55-159.................................................... 8 55-160.................................................... 8 55-171.................................................... 9 55-172.................................................... 9 55-173.................................................... 9 55-174.................................................... 9 55-176.................................................. 10 55-177.................................................. 10 55-186UC............................................. 33 55-188.................................................. 31 55-200.................................................. 19 55-201.................................................. 19 55-202.................................................. 19 55-203.................................................. 19 55-204.................................................. 19 55-221.................................................. 15 55-223.................................................. 15 55-233.................................................. 13 55-234.................................................. 13 55-235.................................................. 13 55-236.................................................. 13 55-240.................................................. 12 55-241.................................................. 12 55-242.................................................. 12 55-243.................................................. 12 55-244.................................................. 11 55-245.................................................. 11 55-246.................................................. 11 55-247.................................................. 11 55-252.................................................. 20 55-253.................................................. 20 55-254.................................................. 20 55-312.................................................. 27 55-313.................................................. 26 55-320.................................................. 32 55-368PAi............................................ 24 55-451.................................................. 25 55-461.................................................. 30 55-465.................................................. 28 55-562PA-M. ....................................... 29 65-026.................................................. 53 65-030.................................................. 53 70-316.......................................47, 49, 52 70-318.................................................. 53 70-511.......................................47, 49, 53 70-512............................................ 51, 53 70-600.................................................. 51 70-700.................................................. 51 75-063............................................ 43, 53 75-064............................................ 43, 53 75-067.................................................. 45 75-068.................................................. 44 80-015.......................................47, 49, 52 80-030.................................................. 52 85-208.................................47, 49, 51, 53 i i i I . . . INDEX
